Substituting values for a, b and c determines the filter response over frequency. Thus, the denominator of the transfer function for any second-order lowpass filter is as²+ bs + c. Simple RC lowpass filters have the transfer function:Ĭascading such filters complicates the response by giving rise to quadratic equations in the denominator of the transfer function. Consequently, this discussion employs a minimum of math-either in translating the theoretical tables into practical component values, or in deriving the response of a general-purpose filter.
Filter design from theoretical equations can prove arduous. Unfortunately, filter design is based firmly on long-established equations and tables of theoretical results. This article clears a path through the brush for the practical engineer and unravels the mystery of filter design, enabling you to design continuous-time analog filters quickly and with a minimum of mathematics.Īnalog electronics has two distinct sides: the theory taught by academic institutions (equations of stability, phase-shift calculations, etc.), and the practical side familiar to most engineers (avoid oscillation by tweaking the gain with a capacitor, etc.). The countless pages of equations found in most books on filter design can frighten small dogs, and digital designers. You never get to see him, even with an appointment, and you call him "Sir." The guru of analog engineers is the Analog Filter Designer, who sits on the throne of his kingdom and imparts wisdom. Known throughout the land for their esoteric expertise, this is the tribe of the Analog Engineers, who live in the farthest regions of the left half Plains, past the jungles of Laplace. Constrain the filter order to 120.A small tribe, in the dense wilderness, is much sought after by head hunters from the surrounding plains. The passband ripple is 0.01 dB and the stopband attenuation is 80 dB. The stopband-edge frequency is determined as a result of the design.ĭesign a lowpass FIR filter for data sampled at 48 kHz. This function designs optimal equiripple lowpass/highpass FIR filters with specified passband/stopband ripple values and with a specified passband-edge frequency. In the DSP System Toolbox, the preferred function for lowpass FIR filter design with a specified order is firceqrip. FIR design functions in the Signal Processing Toolbox (including fir1, firpm, and firls) are all capable of designing lowpass filters with a specified order.
Another common scenario is when you have computed the available computational budget (MIPS) for your implementation and this affords you a limited filter order. One such case is if you are targeting hardware which has constrained the filter order to a specific number. There are many practical situations in which you must specify the filter order. FIR Lowpass Designs - Specifying the Filter Order However, the use of minimum-phase and multirate designs can result in FIR filters comparable to IIR filters in terms of group delay and computational efficiency. IIR filters also tend to have a shorter transient response and a smaller group delay. IIR filters are generally computationally more efficient in the sense that they can meet the design specifications with fewer coefficients than FIR filters.
IIR filters (in particular biquad filters) are used in applications (such as audio signal processing) where phase linearity is not a concern. FIR filters are also used in many high-speed implementations such as FPGAs or ASICs because they are suitable for pipelining. FIR filters also tend to be preferred for fixed-point implementations because they are typically more robust to quantization effects. You generally choose FIR filters when a linear phase response is important. When designing a lowpass filter, the first choice you make is whether to design an FIR or IIR filter.
